Leverage leading-edgesenior care technology

Vayyar Care: The Next Generation of Imaging isn’t Camera-based

Vayyar Care: The Next Generation of Imaging isn’t Camera-based

Vayyar Care uses optics-free radio frequency technology to provide 24/7 touchless monitoring. The device works in all lighting conditions, dense steam, and high humidity, generating 4D point cloud imaging that protects people and respects their privacy.
Plastic case
(front)
RF module
RF/DSP fully integrated chip
Heatsink
Digital communication board
Plastic case
(back)

4D imaging radar: unprecedented protection

Vayyar Care’s advanced sensor technology

• mmWave MIMO (Multiple Input Multiple Output) radio frequency sensor
• Operates in the 60 GHz frequency band
• Supports a 1400 azimuth (horizontal) and 700 elevation (height) field of view
• Wall-mounted sensor (1.5m / 5 feet off floor) monitors a coverage area of 16m2 / 169ft2

Smart, compact, robust and efficient

Delivering the reliability that ensures peace of mind

• Communicates via 2.4 GHz Wi-Fi (802.11 b/g/n) with Vayyar Cloud based on Google services
• 9cm (3 ½”) diameter, 1.5cm (23”) depth and weighs only 110g (4oz)
• Operates in temperature range of 0-400C (32–1040F) and at up to 95% humidity
• 5V input voltage fed from AC/DC transformer provided with the device – peak power consumption of just 10W

It’s the safest sensor technology there is

Trusted by senior living communities around the world

• Uses harmless radio frequency waves 1,000 times weaker than a cell phone signal
• Fully FCC-approved
• Authorized for use across the US, UK, Europe, China, Taiwan, Canada, Australia, and Japan

In darkness

Vayyar Care works in pitch darkness, providing complete protection when the risk of a fall is higher.

In steam

It even operates in dense steam, safeguarding seniors in bathrooms where slips and trips often happen.

In private

Because the device doesn’t depend on cameras, it maintains privacy at all times, but can detect movement through curtains!

In darkness

Vayyar Care works in pitch darkness, providing complete protection when the risk of a fall is higher.

In steam

It even operates in dense steam, safeguarding seniors in bathrooms where slips and trips often happen.

In private

Because the device doesn’t depend on cameras, it maintains privacy at all times, but can detect movement through curtains!

Gathering rich data demands cutting-edge mmWave 4D imaging.

Vayyar Care detects room presence, used by communities for wander management and loneliness prevention, and to ensure efficient emergency evacuations. The system tracks the times and frequency of bathroom visits, which can highlight potential UTIs or the side-effects of medication.

Extensive MIMO array houses up to 46 antennas.

Highly integrated RFIC incorporates a DSP, MCU and all other analog and digital radio frequency components.

Low-power radio waves in the 60 GHz frequency band.

Touchless technology
Fully automatic: no hard-to-reach buttons or cords, embarrassing wearables or mats that must be frequently replaced
Multifunctional sensing
Instant fall detection and a wide range of presence-based activity tracking all supported by just one device
Wide field of view
140⁰ FoV provides maximum room coverage with no blind spots, ensuring complete protection and visibility
Small form factor
Compact unit designed for discreet, unobtrusive wall or ceiling installation and easy integration with existing nurse call systems
High resolution
Accurate, robust performance in all lighting conditions and even dense steam, minimizing false positives
Long-range scanning
One device monitors an area measuring up to 16m²/169ft², making it ideal for senior care community bedrooms and bathrooms
Mains-powered
Supports 12/24V DC and AC power supply for straightforward installation and reliable operation
Over-the-air updates
New features are deployed remotely; requires one-time installation and no additional technician visits
vayyarcare-fall-detected-50

Fall Detected

Up to 50 seconds
vayyarcare-40sec-response

Fall Confirmed

Up to 40 seconds
vayyarcare-alarm-30

Alarm Sounds

30 seconds

Comprehensive coverage

Fall Detection

Prevent long lies & flag hidden falls

Imminent Bed Exits

Enable timely intervention

Room Presence

Enhance resident safety and security

Night-time Wandering

Protect memory care patients

Bathroom Frequency

Identify potential medical issues

Time at Rest

Track mobility levels over time

Fall Detection

Prevent long lies & flag hidden falls

Imminent Bed Exits

Enable timely intervention

Room Presence

Enhance resident safety and security

Night-time Wandering

Protect memory care patients

Bathroom Frequency

Identify potential medical issues

Time at Rest

Track mobility levels over time

Evaluation Vayyar's cloud and dashboard

Deployment Customer's cloud and dashboard

Wi-Fi
Dry Contact
